DEVICE TORQUE TEST SYSTEMS

TORQUE INSPECTOR

The Torque Inspector

.

As the industry leader in the precision torque test equipment market, Vibrac continues to develop advanced technological solutions to industrial torque testing problems. Over fifty years of experience in the field of torque measurement has resulted in the development of this patented digital measuring system. The Model 2500 Torque Inspector is an innovative, cost-effective bench top system for measuring the torque

characteristics of rotating devices. It has been used to test devices such as fasteners, gas caps, window cranks, medical devices, military components, night vision apparatus, and helicopter links, among numerous others. Easy-to-use programming features enable the user to tailor a test to the requirements of almost any application.

Torque Testing Made Easy!

The new Torque Inspector, with a Windows-based control software, and touch screen display and interface, proves that torque testing is now simple, accurate and affordable. This compact system measures and stores test results at the touch of a button. Features include:

  • Simple touch screen programming

  • Automatic testing and data logging

  • Completely calibratable in the field

  • NIST traceable calibration

  • Instant on; no warm-up period

  • Wide operating temperature range

  • Mechanical overload protection

  • RS 232 output port

  • USB data upload/download port

  • Full one-year warranty

The Torque Inspector come in a vertical and horizontal option, based on your testing needs.

The Torque Inspector provides accurate and reliable information that allows you to track performance and predict potential problems before they occur. By using data provided by the Torque Inspector, you are able to rapidly identify problem situations and make corrections, thereby eliminating unnecessary expenses caused by defects. Additional benefits gained by using the Torque Inspector for your torque testing are:

  • The ability to perform non-destructive testing.

  • Eliminate physical injuries related to the repetitive motion of manual testing (such as Carpal Tunnel Syndrome and tendinitis).

  • Data output is in a digital format, as required for ISO 9000 series documentation and certification.

  • Produces repeatable results for simplifying reporting for quality standards verification.

  • Assistance in selecting the correct system for each application.

  • Availability of on-site training and demonstration of the system

Torque Inspector Easily Selected Test Features

.

From a simple move test to a multi-cycle bi-directional test, with run-ins and naps, the Torque Inspector does it all.

Select a Profile From Memory

.d

A library of tests can be easily created to make the operator's job simple and efficient.

Calibrate On-Site.

The Torque Inspector comes with a Certificate of Calibration that assures traceability to NIST standards. System repeatability and calibration can be verified on site simply by running a sample test with our "Gold Standard" (an optional magnetic torque device, set to a predetermined torque at our factory). Calibration can even be performed at any time without returning the system to the factory. Although we recommend having one of our technicians perform the calibration, you can perform this procedure by using a Vibrac Calibration Kit and by following the simple on-screen instructions and pictures which will guide the user through the complete calibration process.

Built for the Factory Environment.d

This metal-housed unit with its abrasion-resistant finish can withstand the dust and liquid spills that occur during normal factory use. The display screen arm and housing are made using heavy gage aluminum to prevent damage from lifting, bumping and other common impact situations.
